Service Depth - - - - - - - - - - 16,000'
Workover Depth - - - - - - - - 10,000'

Carrier - - - - - 5 Axles
High Tensile Alloy Wide Flanged Beam
Front Axles: 20,000# Capacity
Suspension: Spring
Rear Axles: 46,000# Tandem
Suspension: Walking Beam
Push Axle: 25,000# Capacity
Front Tires: 385/65R22.5
Rear Tires: 11R22.5

Power Train
Engine – MTU S1300 T4
      or   – FPT Cursor 13
Transmission – 4500 OFS Allison

Main Drum
Brakes: 42" diameter x 12" wide
Water spray brake cooling
Double 48” Air Cooled Disc Assist
Barrel: 16" diameter x 38" wide
Chain: Double 140 Clutch: 324
Shaft: 6.60" Lebus Grooving: 1" or optional 1 1/8”

Sand Drum
Brakes: 42" diameter x 8" wide
Water spray brake cooling
Barrel: 16" diameter x 43" wide
Chain: Double 140 Clutch: 224
Shaft: 5.90"
Capacity: 14,400'- 9/16" or 11,800' - 5/8"

104’ MAST
Clear Height 104’
Maximum Static Load:

200,000# Capacity w/ 4 lines
250,000# Capacity w/ 6 lines

Tubing Board Capacity:
110,600# Pipe Setback Load

Rod Board Capacity:
31,208# Static Rod Load

Also available with our

104‘ MAST
Clear Height 104’
Maximum Static Load:
300,000# Capacity w/ 6 lines

Tubing Board Capacity:
143,500# Pipe Setback Load

Rod Board Capacity:
31,208# Static Road Load
