Service Depth - - - - - - - - - - 8,500'
Workover Depth - - - - - - - - 7,500'

Carrier - - - - - 4 Axles
High Tensile Alloy Wide Flanged Beam
Front Axle: 20,000# Capacity
Suspension: Spring
Rear Axle: 46,000# Tandem
Suspension: Walking Beam
Front Tires: 385/65R22.5
Rear Tires: 11R22.5

Power Train
Engine – MTU S1300 T4
      or   – FPT Cursor 13
Transmission – 4500 OFS Allison

Main Drum
Brakes: 38" diameter x 10" wide
Water spray brake cooling
Optional 40" Air Cooled Disc Assist
Barrel: 12.75" diameter x 41.75" wide
Chain: Single 140 Clutch: 224
Shaft: 5.95" Lebus Grooving: 1"

Sand Drum
Brakes: 38" diameter x 8" wide
Barrel: 12.75" diameter x 41" wide
Chain: Single 140 Clutch: 124
Shaft: 4.75"
Capacity: 12,500'- 9/16" or 10,000' - 5/8"



71’ MAST
Clear Height: 71’
Maximum Static Load:
150,000# Capacity w/ 4 lines
180,000# Capacity w/ 6 lines

Tubing Board Capacity:
23,500# Pipe Setback Load

Rod Board Capacity:
10,760# Static Rod Load
